Nanlux

Evoke 150C 8-Chip LED Spotlight

Name: Evoke 150C 8-Chip LED Spotlight
Brand: Nanlux
SKU: EV150C
Price: 1080.00 USD
Availability: InStock

Evoke 150C 8-Chip LED Spotlight

$1,080.00 USD

Sale Sold out

SKU:EV150C

TOP QUALITY LIGHT
Equipped with the Nebula C8 light engine, Evoke 150C produces the highest possible quality of light with the deepest saturation, warmest CCT, and widest color gamut

EASY SETUP
The all-in-one design has no external power supply—just a single cord that plugs into one port for both AC and DC power; it's fast and easy to set up and wrap

VIVID COLORS, WIDE CCT
Easily produce everything from intensely saturated colors to subtle hues and utilize the ultra-wide 1000K–20000K CCT range with ±200 of G/M adjustment

WEATHERPROOF
Features all-weather protection with a rating of IP66, freeing you to work on location in rain or dust storms without worry

SUPPORTED IN THE USA
Evoke 150C is built tough, comes with a 2-year limited warranty that extends to 3 years with registration, it's stocked, supported, and serviced in the USA, and features a modular design with easy-to-replace parts

The Nanlux Evoke 150C is a powerful and compact LED spotlight with an unparalleled 8-chip light engine that mixes Deep Red, Red, Amber, Lime, Green, Cyan, Blue, and Indigo LEDs to deliver vivid colors and a notably wide and accurate CCT range of 1000K-20000K with ±200 of G/M adjustment.

View full details

Unique Photometrics Chart

☀ Photometrics

Bare Bulb CCT		Bare Bulb Color
@ 1m 3200K	12120 lux / 1126 fc	@ 1m Red	1705 lux / 158 fc
@ 2m 3200K	2921 lux / 271 fc	@ 2m Red	398 lux / 37 fc
@ 3m 3200K	1320 lux / 123 fc	@ 3m Red	179 lux / 17 fc
@ 1m 5600K	12160 lux / 1130 fc	@ 1m Green	5680 lux / 528 fc
@ 2m 5600K	2940 lux / 273 fc	@ 2m Green	1365 lux / 127 fc
@ 3m 5600K	1328 lux / 123 fc	@ 3m Green	615 lux / 57 fc
		@ 1m Blue	1600 lux / 149 fc
		@ 2m Blue	386 lux / 36 fc
		@ 3m Blue	174 lux / 16 fc
25° Reflector CCT		25° Reflector Color
@ 1m 3200K	85400 lux / 7934 fc	@ 1m Red	10160 lux / 944 fc
@ 2m 3200K	14030 lux / 1303 fc	@ 2m Red	1607 lux / 149 fc
@ 3m 3200K	5570 lux / 517 fc	@ 3m Red	645 lux / 60 fc
@ 1m 5600K	83500 lux / 7757 fc	@ 1m Green	38700 lux / 3595 fc
@ 2m 5600K	13730 lux / 1276 fc	@ 2m Green	6300 lux / 585 fc
@ 3m 5600K	5460 lux / 507 fc	@ 3m Green	2520 lux / 234 fc
		@ 1m Blue	10920 lux / 1014 fc
		@ 2m Blue	1784 lux / 166 fc
		@ 3m Blue	712 lux / 66 fc

Specifications Table

⚙ Specifications

LED Light Engine	Nebula C8 Light Engine: dRRALGCBI
CCT	1000K-20000K (G/M±200)
CRI	Average 98
TLCI	Average 98
SSI 3200K	86
SSI 5600K	78
TM-30 RF (Average)	96
TM-30 RG (Average)	100
Beam Angle	47°
Rated Power	150W
Input Voltage/Current	AC100-240V/50-60Hz, 2A Max, DC14.4-28V, PD3.0 (12-28V) 60w Min
Dimming	0–100% by 0.1% Increments
Effects	CCT Loop, INT Loop, HUE Loop, Flash, Pulse, Storm, Police Car, TV, Paparazzi, Candle/Fire, Disco, Bad Bulb, Firework, Explosion and Welding
Control	On-board, Wired Controller, Nanlink App, Remote Controller, DMX/RDM, LumenRadio CRMX, Art-Net/sACN,NFC (*via the Extension Adapter)
DMX Dimming Curve	Linear, Exponent, Logarithm, S Curve, Gamma 2.2, Gamma 2.4, Gamma 2.6
Dimensions	8.23 × 5.79 x 5.01" (20.9 × 14.69 x 12.72cm)
Weight	4.65lbs (2.11kg)
